Válec sněžného pluhu: 1,5″ vrtání, 12″ zdvih, 1,25″ tyč

Snowplow Cylinder: 1.5″ Bore, 12″ Stroke, 1.25″ Rod Type: Welded

Action: Single-Acting

Bore (ID): 1.5″

Stroke: 12″

Rod (OD): 1.25″

Mounting Type: Hole

Mounting Pin (OD): 1″

Rod End Type: Hole

Rod End Pin (OD): 1″

Work Ports: 1/4″ NPT(F)

Max Working Pressure: 3,000 PSI

Retracted Length: 19.25″ (pin to pin, center on center)

Extended Length: 31.25″ (pin to pin, center on center)

Cylinder Length: 20.75″ (retracted, edge to edge)

Column Load: 5306 lbs

Product Weight: 15.6 lbs

Barrel Material: Quenched and tempered steel (ASIS 1020)

Rod Material: High tensile ground and polished chrome plated steel (ASIS 1045)

Gland Material: High tensile nodular cast iron (ASTM A536 grade 70-50-05)

Piston Material: High tensile nodular cast iron (ASTM A536 grade 70-50-05)
